Sunivision 1080P HD 4 channel software dvr h 264
- Place of Origin:
-
Guangdong, China
- Brand Name:
-
sunivision
- Model Number:
-
AP-9624HV
- Video input(BNC)/output:
-
4/1
- Audio input/output:
-
4/1
- Alarm input/output:
-
4/4
- Playback synchronou sly MAX:
-
4CH
- HDD qty:
-
2
- Maximun of each HDD:
-
2T
- Maximun of total HDD:
-
4T
- CMS software:
-
yes
- Flash memory backup:
-
yes
- VGA:
-
1
Sunivision 1080P HD 4 channel software dvr h 264
Fuctions
1.H.264 video compression
2. 4-channel usb dvr
3.support multiplex
4.support D1,HD1.CIF recording resolutions,4CH realtime D1 record
5.support PTZ control via built-in RS-485 port
6. Support 26 languages
Specifications
|
Video Compression Format |
H.264 |
|
Video System |
NTSC / PAL |
|
GUI OSD |
YES |
|
Video Input(BNC) |
4CH BNC input(composite video signal 1Vp-p 75Ω BNC) |
|
Video Output(BNC) |
1CH BNC output |
|
Audio Input/Output |
4CH audio input,1CH audio output(RCA) |
|
Maximum Recording Rate(CIF/HD1/D1) |
CIF:352×240 pixels with 480 IPS /352×288 pixels with 400 IPS HD1:704×240 pixels with 224 IPS /704×288 pixels with 192 IPS D1:704×480 pixels with 112 IPS /704×576 pixels with 96 IPS |
|
Image Quality Setting |
Supper Best,Well,Good,Medium,Normal and Bad |
|
Hard Disk Storage |
Support 2 SATA HDD,each max upto 4TB |
|
Alarm Input/Output |
4CH alarm input/4CH alarm output |
|
Multiplex Operation |
Live display/record/playback/backup/network transmit |
|
Recording Mode |
Manual/Timer/Motion |
|
Playback Mode |
Multiple slow and rapid play speeds,manual and single-frame play modes,and support of drag the sliding bar to set.
|
|
Backup Device |
USB flash disk/Network backup |
|
Pre-alarm Recording |
Recording for 10 seconds before alarming |
|
Network Protocol |
TCP/IP,PPPOE ,DDNS and NTP |
|
Ethernet remote view |
Support remote surveillance up to 10 users simultaneously |
|
CMS software |
YES |
|
Mobilephone View |
YES |
|
VGA Interface |
YES |
|
Log record function |
YES |
|
Image Tour |
YES |
|
IR Remote control |
YES |
|
Video Loss Detection |
YES |
|
Video Adjustable |
Hue /Saturation /Contrast /Brightness adjust |
|
PTZ Control |
YES,built-in RS-485 port |
|
USB Mouse |
YES |
|
Power Source |
DC 12V |
|
Key Lock(Password Protection) |
YES |
|
Power-down recovery function |
YES |
|
|
